YAWA TYM 790

Year : 2014 Condition: very good

Available: September / October 2024

Die Cutting and Hot Foil

* counter status 10.5 mil

Technical specifications:

Maximum sheet format - 790 x 560 mm

Min sheet format - 310 x 210 mm

Maximum cut-out format - 750 x 520 mm

Maximum gilding area - 750 x 525 mm

Height of cutting knives - 23.8 mm

Maximum pressure - 120 t

Cutting sheets - 5 mm, 4 + 1

Weight:

* paper min 100 gsm

* cardboard 157 – 2000 gsm

* corrugated cardboard E,B up to 1.5 mm

Minimum catch edge - 6 mm

Maximum cutting speed - 5500 sheets/h

Maximum gilding speed - 4000 sheets/h

Film unwinders - 3 in the direction of the paper path, 2 perpendicular to the paper direction

Max. diameter of the foil roll - 210 mm

Socket diameter - 3"

Max. loader stack height - 1200 mm

Max. stack height unloader - 950 mm

Power consumption - 21 kw

Dimensions - 4000 x 3560 x 2210 mm

Weight - 7500 kg

Loader

* Dual action loading suction head with blower

* Non-stop loader

* Setting the position of the pallet in the loader

* Electromechanical double sheet control

* Independent speed control of feeding belts

* Three-way loading table system for optimal synchronization between the loader and the die-cutting unit at different time dimensions of the sheet

* Pulling and pushing side attachments to ensure maximum cutting accuracy

* 4 adjustable front pads with optical control of the sheet travel

Cutting unit

* Proven drive system with moving bottom plate

* Stationary top plate with increased resistance

* Pneumatic clutch / brake

* Motorized setting of cutting pressure

* System of precise positioning of the catcher rod during a functional stop

* Safety clutch to protect the drive of the catch bars

* Central lubrication

Gilding unit

* 5 independently programmable shafts

* For film unwinding 2 in the direction of the paper path, 2 perpendicular to the direction of passage

* 6 independent heating zones

* 24-hour programmable heating

* Signaling of film running out

* Air separation foil

Unloading:

* Nonstop unloader

* Sheet braking

* Optical control of unloading and sheet loss

* Aeration system for reliable unloading

* Rear and side cellarers for leveling the stack

* Chain tensioning

* CE certificate
